The unique multi-function, mini device that encodes a 12G-SDI/4K60 video stream such as RTMP/ RTSP/ SRT/ Full NDI/ HX2/ HX3 and decodes the NDI PGM returning back from a switch or remote simultaneously, which can be monitored in real-time.
Vela Rack SDI has high quality video encoding and up-streaming applied in multi-person remote video connections/ conference/ vocal concert and etc while decoding live streams simultaneously and display to the large screen by HDMI output, truly achieve the broadcast level.
With a 3.4 inch large-size flip touch screen integrated in a small device, high brightness, 960x412 high resolution, natural color, smooth, user-friendly and sensitive UI with convenient functional arrangement and long life span.
Speaker, intercom/ stereo/ audio monitor integrated in the front panel.
Simply record every video at a press of a button, encode format from HD to 4K60, and up to 10bit 4:4:4 quality. Restore pixels, extreme colors, and record in multiple formats such as MOV and MP4.
Pause, Play, Rewind, Fast Forward, or Freeze any frame.
With the C1 SSD Enclosure, there is no limitation on storage space. Choose between different SSD model. Ultra slim design, supports up to 500Mbit/s bandwidth PCIe high-speed bus, record for long periods of time using a single SSD.
| HD | 720p50, 720p59.94, 720p60, 1080i59.94, 1080i60, 1080p23.98, 1080p24, 1080p25, 1080p29,97, 1080p30, 1080p50, 1080p59.94, 1080p60, 2KDClp23.98, 2KDClp24, 2KDClp25, 2KDClp29.97, 2KDClp30, 2KDClp50, 2KDClp59.94, 2KDClp60 |
| UHD | 2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60, 4KDClp23.98, 4KDClp24, 4KDClp25, 4KDClp29.97, 4KDClp30, 4KDClp50, 4KDClp59.94, 4KDClp60 |
| SDI Video Sampling | 4:2:2 |
| SDI Audio Sampling | 48kHz |
| Color Space | BT2020 |
| Storage | NVMe SSD Drive Socket |
| Hardware Structure | FPGA+SOC |
| SDI Input | 1x 3G/ 6G/ 12G-SDI BNC |
| SDI Loop Out | 1x 3G/ 6G/ 12G-SDI BNC |
| HDMI Output | 1x HDMI 2.0 Type A supports up to HDMI 4K60 output |
| RJ45 Gigabit Ethernet | 1x Gigabit Ethernet |
| LINE IN | 1x Line In 3.5mm for Analog Audio Embed |
| Headset/Mic | 1x 3.5mm Analog Audio Input & Output |
| Optical Fiber Transceiver | 1x Ethernet Optical SFP socket |
| Installation Method | Desktop, Came-Mounted, Rack-Mounted |
| 1/4" Screw Hole | 1/4" Hole |
| Control | 3.4" TFT Touch Screen, Dyna Hub, Dyna Control |
| Recording Format | MP4 & MOV |
| Encode/Decode Protocol | RTMP/ RTSP/ SRT/ Full NDI/ HX2/ HX3 |
| Supported Software | TriCaster/ vMix/ OBS/ Wirecast/ Streamstar/ Skype/ Zoom/ XSplite/ Webex/ Watchout/ GoToMeeting |
| Restore | ✓ |
| Audio Mixer | ✓ |
| Intercom | ✓ |
| Tally |
Green/ Preview Red/ Program |
| Power Supply |
9-18VDC PoE |
| Dimensions | 255mm x 163mm x 51mm |
| Weight | 620g |
