4K30 high-definition image
3x optical zoom
USB & HDMI simultaneously output
Power via USB-C
Easy deployment and easy control
4K30 high-definition image
3x optical zoom
USB & HDMI simultaneously output
Power via USB-C
Easy deployment and easy control
Simultaneous USB and HDMI output allows you to connect to multiple devices at once, providing seamless integration into diverse setups. Whether in a boardroom, classroom, or live production environment, this dual output capability enhances your workflow and expands your presentation capabilities.
The Meet+ 3 powers directly via a USB-C port, eliminating the need for a power supply adaptor. This simplifies deployment with a single cable for power, video, and control.
Boasting a 3X optical zoom and a wide 90-degree field of view, this camera conquers the challenges of small rooms. Zoom in for crystal-clear close-ups without sacrificing image quality, or effortlessly capture the entire scene in a single frame. This versatile combination ensures clear communication and a natural video conferencing experience, no matter the space.
With a 20X optical zoom lens and a 60-degree field of view, the Drive+ SE ensures rapid, accurate focus with its proprietary algorithm. Capture every detail effortlessly, whether zooming in or panning.
Thanks to the compact and sophisticated mechanism design, and accurate driven algorithms, Meet+ 3 can move very smoothly without noise at variable pan/tilt/zoom speed.
| Camera | |
| Part NO. | TLC-1000-HU2-3-4K |
| Sensor | 1/3-inch, 8.4 MP CMOS Panasonic sensor |
| Zoom | 3X optical zoom + 12X digital zoom |
| Lens | f = 3.3mm ~ 9.7 mm, F2.0-3.7 |
| Horizontal View Angle | 90° (wide) ~ 31.3° (tele) |
| Vertical View Angle | 50.5° (wide) ~ 18.2° (tele) |
| Diagonal View Angle |
|
| Minimum Working Distance | 1.0m |
| S/N Ratio | ≥50dB |
| Image Parameters | |
| Noise Reduction | 2D&3D |
| Minimum lux | 0.7 Lux (50 IRE Max AGC, 1/30, F1.8) |
| White Balance | Auto / Manual / indoor / Outdoor / C.T. / PUSH |
| Exposure | Auto / Manual / Shutter Priority |
| Anti-flicker | OFF, 50Hz, 60Hz |
| Image Flip/Mirroring | Supported |
| Focus/Iris/Electronic-shutter | Auto / Manual |
| Gamma | Supported |
| WDR | Supported |
| Video Format | |
| HDMI |
|
| USB 2.0 Type-C |
MJPG
YUY2
|
| Pan/Tile Movement | |
| Preset |
|
| Pan Rotation Angle | -170°~+170° |
| Tilt Rotation Angle | -30°~+90° |
| Pan Rotation Speed | 0.1°~120°/s |
| Tilt Rotation Speed | 0.1°~80°/s |
| General | |
| Input Voltage | DC12V |
| Operating Temperature | -10°C ~ 50°C |
| Operating Humidity | ≤80% |
| Dimension (L×W×H) | 148mm x 132mm x 162mm |
| Net Weight | 0.85kg (1.85LBS) |
| Color | Silver |
| Accessory |
|
