1080p high-definition image
12x/20x optical zoom
72.5-degree FOV
Power via USB3.0 port
1080p high-definition image
12x/20x optical zoom
72.5-degree FOV
Power via USB3.0 port
The Meet+ 12-U3/Meet+ 20-U3 webcam features USB 3.0 video output for smooth visuals and fast plug-and-play functionality. No need to install drivers or software – simply connect it to your computer’s USB port for automatic recognition as your video and audio source. Telycam Meet+ 12-U3/Meet+ 20-U3 PTZ cameras utilize USB 3.0 for fast video transmission and minimal latency, ensuring reliable, top-quality video for live streaming, video conferencing, and recording right out of the box.
Equipped with advanced image processing, cutting-edge algorithms, a 1/2.8-inch sensor, and a high-quality lens, it outputs crystal clear images up to 1080p60 FHD resolution.
The Meet+ 12-U3/Meet+ 20-U3 powers directly via a USB 3.0 port, eliminating the need for a power supply adaptor. This simplifies deployment with a single cable for power, video, and control.
Uses truly 12X optical zoom lens with 72.5-degree wide angle FOV or 20X optical zoom lens with 60-degree wide angle FOV, fast and accurate focus performance to capture details in large and middle room.
Thanks to the compact and sophisticated mechanism design, and accurate driven algorithms, Meet+ 12-U3/Meet+ 20-U3 can move very smoothly without noise at variable pan/tilt/zoom speed.
The Meet+ 12-U3/Meet+ 20-U3 webcam seamlessly works with a wide range of popular virtual meeting platforms, including Microsoft Teams, Zoom, Webex, Google Meet, and Skype. This means you can hop on calls with colleagues, friends, or family using your preferred platform without worrying about compatibility issues. No matter which platform you choose, the Meet+ 12-U3/Meet+ 20-U3 will ensure you’re seen and heard clearly.
| Meet+ 12-U3 | |
| Part NO. | TLC-300-U3-12P |
| Sensor | 1/2.8 inch, 2.4MP CMOS sensor |
| Zoom | 12X optical zoom, 12x digital zoom |
| Lens | f = 3.92~46.8mm, F1.6~F2.8 |
| Horizontal View Angle | 72.5° (wide) ~ 6.48° (Tele) |
| Vertical View Angle | 42.72° ~ 3.66 |
| Diagonal View Angle | 78.58° ~ 7.42° |
| Minimum Working Distance |
|
| S/N Ratio | ≥50dB |
| Meet+ 20-U3 | |
| Part NO. | TLC-300-U3-20P |
| Sensor | 1/2.8 inch, 2.4MP CMOS sensor |
| Zoom | 20X optical zoom, 20x digital zoom |
| Lens | f = 4.9~98mm, F1.5~F3.0 |
| Horizontal View Angle | 60° (Wide) ~ 3.2° (Tele) |
| Vertical View Angle | 32.2° ~ 1.8° |
| Diagonal View Angle | 61° ~ 3.64° |
| Minimum Working Distance |
|
| S/N Ratio | ≥50dB |
| Image Parameters | |
| Noise Reduction | 2D&3D |
| Minimum lux | 0.7 Lux (50 IRE Max AGC, 1/30, F1.8) |
| White Balance | Auto / Manual / Indoor / Outdoor / Push / Sodium / Fluorescent |
| Focus/Iris/Electronic-shutter | Auto / Manual |
| Backlight Compensation | Supported |
| Video Format | |
| USB 3.0 |
YUY2
|
| USB 2.0 |
YUY2
|
| Pan/Tile Movement | |
| Preset | 128 presets via RS232, 10 presets via remote controller |
| Pan Rotation Angle | -170°~+170° |
| Tilt Rotation Angle | -30°~+90° |
| Pan Rotation Speed | 0.1°~120°/s |
| Tilt Rotation Speed | 0.1°~80°/s |
| Control | RS232 / RS485 / USB / Remote Controller |
| Video Port | USB 3.0 |
| General | |
| Input Voltage |
|
| Power Consumption | DC: 12V 2A (Pmax = 8W) |
| Operating Temperature | -10°C ~ 50°C |
| Operating Humidity | ≤80% |
| Dimension (L×W×H) | 220mm × 190mm × 173mm |
| Package Dimension | 32 x 30 x 31cm |
| Color | Silver |
| Package Content |
|
