Converts up to four IP streams into one 4Kp60 HDMI signal
Connects baseband presentation or distribution equipment into IP-based media networks
Stays compatible with popular video formats and streaming protocols
Supports HDR10
Video preview, in real-time stream or MJPEG picture is available on the web GUI
Remote centralized management via Control Hub or Zixi ZEN Master
Interface
specifications
Features
Decoding Features
Support NDI High Bandwidth, NDI HX, NDI HX2, NDI HX3, SRT, MPEG-TS over RTP/UDP/RIST, RTMP, RTSP, HLS, HTTP, and ZIXI protocols
Support multiview layouts
For Single View, support decoding 1 stream of H.264, H.265, SpeedHQ or MPEG2 at up to 4096x2160p60
For Picture-in-Picture, support decoding 2 streams of H.264, H.265, SpeedHQ or MPEG2 at up to 1920x1080p60 (Only one NDI High Bandwidth or one MPEG2 format video signal can be decoded.)
For Quad view, support decoding 4 streams of H.264 or H.265 at up to 1920x1080p60
Support decoding audio in AAC, MP3, AC3, Opus, and G.711 formats
Support NDI 6.3
Output Features
Max output: 2560x1440 60fps 4:4:4 10-bit
Support 48/96KHz 8-channel audio output
Support HDR10
Others
Advanced configuration and device status through intuitive Web GUI, keyboard/mouse, or on-board controls
Register with Control Hub or Zixi ZEN Master for remote centralized management
Support preview of output images and PTZ control
Provide HTTP APIs
LED status indicators
Form factor: 4.72 in (L) x 3.12 in (W) x 0.96 in (H) (120 mm x 79.3 mm x 24.5 mm)
Details
Accessory
Included
Pro Convert IP to HDM 4KI x1
Part number: 64410
Universal power adapter x1
Part number: ELE00125
USB Type C to Type C cable x1
Part number: ELE00114
USB Type C to Type A cable x1
Part number: ELE00066
Fishtale Bracket x1
Part number: STR00211
Bracket Fasteners x1
Part number: PAR10040
M4*12 Black Screws x2
Part number: MECO0067
M4 Black Nuts x2
Part number: MECO0068
We recommend you always use the included accessories to avoid unnecessary damage to your device.
Please note, the appearance of the power adapter may vary due to suppliers or batches. The images here are for reference only.
