The Ultra Encode family of live media encoders offers systems integrators, streaming professionals and OEM partners a powerful range of flexible, reliable and cost-effective encoding solutions for applications including live streaming, AV over IP, remote contribution, IP production and workflows and much more.

Flexible Format and Protocol Support

The Ultra Encode family supports H.264 and H.265 (HEVC) encoding and a wide range of streaming protocols including RTMP, RTMPS, SRT, RTSP, RTP, HLS, and TVU’s ISSP technology. Support for NDI® HX video connectivity technology also makes the Ultra Encode family ideal for IP-based production and distribution.

Powerful Live Streaming to Multiple Platforms

For live streaming applications, Ultra Encode devices can stream to multiple target destinations simultaneously. Configurable presets enable easy streaming to popular platforms including YouTube™ Live, Facebook™ Live and more.

Pair with Pro Convert

Ultra Encode devices can be combined with Magewell’s multi-format Pro Convert decoders to form robust, end-to-end, live media transport infrastructures using NDI® HX or streaming formats.

Centralized Management

All Ultra Encode models can be centrally configured and controlled through our powerful Control Hub management software (sold separately). You can easily manage multiple Ultra Encode devices across multiple locations through an intuitive, browser-based interface.

Choose Your Ultra Encode Model

The Ultra Encode family is available in a choice of models to meet your specific functionality and format requirements:

Ultra Encode HDMI/SDI (Rev B)

Ultra Encode HDMI/SDI Plus

Ultra Encode AIO
Input & loopthrough interfaces HDMI (Ultra Encode HDMI) or SDI (Ultra Encode SDI) HDMI (Ultra Encode HDMI Plus) or SDI (Ultra Encode SDI Plus) HDMI and SDI (encode 1 input or combine both into 1 output)
Max encoding resolution & bitrate (excluding NDI® HX) Main stream: 2048x1080p60 16Mbps
Sub stream: 1080p60 16Mbps
Main stream: 4Kp30 32Mbps
Sub stream: 1080p60 32Mbps
Main stream: 4Kp30 32Mbps
Sub stream: 1080p60 32Mbps
Audio encoding channels 2 8 8
Output audio streams 1 8 8
Encoding Formats H.264, H.265 H.264, H.265 H.264, H.265
Streaming Protocols RTMP, RTMPS, SRT (Caller or Listener), HLS Pull, RTSP, TS over UDP & RTP, TVU ISSP RTMP, RTMPS, SRT (Caller or Listener), HLS Pull, RTSP, TS over UDP & RTP, TVU ISSP RTMP, RTMPS, SRT (Caller or Listener), HLS Pull, RTSP, TS over UDP & RTP, TVU ISSP
Streaming Presets and Integrations YouTube via RTMP, Facebook Live, Twitch YouTube via RTMP or HLS, Facebook Live, Twitch, Wowza over RTMP or SRT YouTube via RTMP or HLS, Facebook Live, Twitch, Wowza over RTMP or SRT
NDI® Support NDI® HX2 NDI® HX2, NDI® HX3 NDI® HX2, NDI® HX3
Simultaneous streaming outputs (*limit 1 output when using NDI® HX) 6 (using same streaming protocol) 6 (multiple streaming protocols) 6 (multiple streaming protocols)
Recording Record to internal storage, external USB drive or NAS Record to SD card, external USB drive or NAS
Power over Ethernet (PoE)
Rack mounting 1RU rackmount shelf and mounting kit (not included) 1RU rackmount shelf and mounting kit (not included) Half-width 1RU with included mounting hardware
